Certifications
Certifications
CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Interface
Audio Interface
N/A
Eelectrical
Power Supply
12V DC ±25%
Power Consumption
Max 3.5W (12V DC, IR on)
Environmental
Operating Conditions
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
* Start up should be done at above -40°C (-40°F)
Storage Conditions
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
Ingress Protection & Vandal Resistance
IP67
Construction
Casing
Aluminium
Dimensions
Φ119mm×97.4mm (Φ4.69"×3.83")
Net Weight
0.37kg (0.82lb)
Gross Weight
0.51kg (1.12lb)
Camera
Image Sensor
1/2.7" CMOS
Effective Pixels
1920(H)×1080(V), 2MP
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/25~1/100000s
NTSC: 1/30~1/100000s
Minimum Illumination
0.02Lux/F1.3, 30IRE, 0Lux IR on
S/N Ratio
More than 65dB
IR Distance
Up to 30m (98feet)
IR On/Off Control
Auto / Manual
IR LEDs
24
Lens
Lens Type
Vari-focal lens / Fixed iris
Mount Type
Board-in
Focal Length
2.7-13.5mm
Max Aperture
F1.3
Angle of View
H: 106°~30°
Focus Control
Manual
Close Focus Distance
200mm
7.87''
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
DORI
Definition
Distance
Wide
Tele
Detect
25px/m (8px/ft)
45m(148ft)
148m(486ft)
Observe
63px/m (19px/ft)
18m(59ft)
59m(194ft)
Recognize
125px/m (38px/ft)
9m(30ft)
30m(97ft)
Identify
250px/m (76px/ft)
5m(15ft)
15m(49ft)
Pan / Tilt / Rotation
Pan/Tilt/Rotation
Pan: 0° ~ 360°
Tilt: 0° ~ 90°
Rotation: 0° ~ 360°
Video
Resolution
1080P (1920×1080)
Frame Rate
25/30fps@1080P, 25/30/50/60fps@720P
Video Output
1-channel BNC high definition video output / CVBS video output (Can switch)
Day/Night
Auto (ICR) / Manual
OSD Menu
Multi-language
BLC Mode
BLC / HLC / DWDR
WDR
DWDR
Gain Control
AGC
Noise Reduction
2D
White Balance
Auto / Manual
Smart IR
Auto / Manual
