> 1/3” 4Megapixel CMOS
> Powerful 30x optical zoom
> H.265 Encoding
> Max. 25/30fps@4M/3M, 25/30/50/60fps@1080P
> Auto-tracking and IVS
> Support PoE+
> IR distance up to 100m
> IP66
Camera
Image Sensor
1/3” CMOS
Effective Pixels
2592(H) x 1520(V), 4 Megapixels
RAM/ROM
1024M/128M
Scanning System
Progressive
Electronic Shutter Speed
1/1s~1/30,000s
Minimum Illumination
Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6; 0Lux@F1.6 (IR on)
S/N Ratio
More than 55dB
IR Distance
Distance up to 100m (328ft)
IR On/Off Control
Auto/Manual
IR LEDs
4
Lens
Focal Length
4.5mm~135mm
Max. Aperture
F1.6 ~ F4.4
Angle of View
H: 60° ~ 2.2°
Optical Zoom
30x
Focus Control
Auto/Manual
Close Focus Distance
100mm~ 1000mm
DORI Distance
Note: The DORI distance is a “general proximity” of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test result according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.
Main stream: 4M/3M(1~25/30fps), 1080P/1.3M/ 720P(1~50/60fps)
Sub stream1: D1/CIF(1 ~ 25/30fps)
Sub stream2: 1080P/1.3M/720P/D1/CIF (1~25/30fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.265/H.264: 448K ~ 8192Kbps
Day/Night
Auto(ICR) / Color / B/W
Backlight Compensation
BLC / HLC / WDR (120dB)
White Balance
Auto, ATW, Indoor, Outdoor, Manual
Gain Control
Auto / Manual
Noise Reduction
Ultra DNR (2D/3D)
Motion Detection
Support
Region of Interest
Support
Electronic Image Stabilization (EIS)
Support
Defog
Support
Digital Zoom
16x
Flip
180°
Privacy Masking
Up to 24 areas
Audio
Compression
G.711a/G.711Mu/AAC/G.722 / G.726/G.729/MPEG2-L2
Network
Ethernet
RJ-45 (10Base-T/100Base-TX)
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP,
ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP,
DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x
Interoperability
ONVIF Profile S&G, API
Streaming Method
Unicast / Multicast
Max. User Access
20 users
Edge Storage
NAS (Network Attached Storage),Local PC for instant recording, Micro SD card 256GB
Web Viewer
IE, Chrome, Firefox, Safari
Management Software
Smart PSS, DSS, DMSS
Smart Phone
IOS, Android
Certifications
Certifications
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB,ANSI C63.4- 2014
UL: UL60950-1+CAN/CSA C22.2,No.60950-1
Interface
Video Interface
N/A
RS485
N/A
Audio I/O
1/1
Alarm I/O
2/1
Electrical
Power Supply
AC24V/3A(±10%), PoE+(802.3at)
Power Consumption
13W,23W (IR on)
Environmental
Operating Conditions
-40°C ~ 70°C (-40°F ~ +158°F) / Less than 95% RH
Ingress Protection
IP66
Vandal Resistance
N/A
Construction
Casing
Metal
Dimensions
Φ186(mm) x 309(mm)
Net Weight
3.9kg(8.60lb)
Gross Weight
7.2kg(15.87lb)
