24 Port Gigabit PoE Switch (24GE PoE + 2GE SFP, Toplam 360W PoE )
24*10/100/1000 Base-T (PoE güç kaynağı), 2*100/1000 Base-X
Anahtarlama Kapasitesi: 52Gbps, Paket İletme Hızı: 38.688Mbps, Mac Tablosu Boyutu: 8K
Paket Buffer: 4MB, NTP, DHCP, LLDP, VLAN, Spanning Tree, Port Aggregiation, Mirroring, Flow Control, Multicast, QoS
Çalışma Sıcaklığı: -10°C~55°C, Nem Aralığı: 5%~95%
Yıldırım Koruması: Common Mod 2KV, Differential Mod 1KV |
PFS4226-24GT-360
24-Port PoE Gigabit Managed Switch
> Layer 2 network management PoE switch
> Support IEEE802.3af, IEEE802.3at standard
> Support Hi-PoE 60W
> Network Redundancy: STP/RSTP/MSTP
> Support IPv4/IPv6, and DHCP
> Network management based on SNMP
> Configuration: Web, Telnet, CLI Command
> QoS (IEEE802.1p/1Q), CoS/ToS to Increase Determinism
> Enhanced Network Security with IEEE802.1X, SNMP v1/v2c/v3, HTTPS, and SSH/SSL
> Large data cache(4M), real-time transmission
> MAC auto study and aging, MAC address list capacity is 8K
> EMC high protection design
|
Technical Speci?cation
|
|
Model
|
DH-PFS4226-24GT-360
|
|
Ethernet Port
|
24*10/100/1000 Base-T (PoE power supply)
2*100/1000 Base-X
|
|
RS232 Serial Console
|
1*RS232 in RJ45 connector with console cable, 115.2Kbps, 8,N,1
|
|
PoE Power Consumption
|
Port1 and port 2 support Hi-PoE 60W
Each power ≤30W, Total≤360W
|
|
PoE Protocol
|
IEEE802.3af, IEEE802.3at, Hi-PoE
|
|
Switching Capacity
|
52Gbps
|
|
Packet Forwarding Rate
|
38.688Mpps
|
|
Packet Buffer Memory
|
4Mb
|
|
Application Humidity
|
5%~95%
|
|
Power
|
AC100-240V, 50/60Hz
|
|
Lightning Protection
|
Common Mode 2KV
Differential Mode 1KV
|
|
Working Temperature
|
-10°C~55°C
|
|
Dimension(W×D×H)
|
440mm x300mm x44mm
|
|
Accessories
|
|
Model
|
|
|
PFT3950
|
1.25G 850nm,500m,LC, Multi-mode
|
|
PFT3960
|
1.25G 1310/1550nm,20km,LC, Single-mode
|
|
PFT3970
|
1.25G 1550/1310nm,20km,LC, Single-mode
|
|
Service Characteristics
|
|
System
|
Username / password: admin/admin
|
|
IP Address :192.168.1.110/24
|
|
PoE Budget
|
Total≤360W
|
|
MAC Table
|
8K
|
|
NTP
|
Support
|
|
DHCP
|
Support DHCP client/server
|
|
Support DHCP snooping
|
|
VLAN
|
802.1Q Standard VLAN
|
|
Port Aggregation
|
Manual aggregation/LACP
|
|
Mirroring
|
Many-to-one port mirroring
|
|
Flow Control
|
Half-duplex based on back pressure type control;
Full duplex based on PAUSE frame
|
|
Multicast
|
IGMP Snooping v1/v2/v3
|
|
Security Features
|
Users management, SSH, HTTPS, SNMP v1/v2/v3, ROMN, ACL, IP source guard, ARP inspection, 802.1x, loop protection
|
|
Spanning tree
|
Support STP/RSTP/MSTP
|
|
LLDP
|
Support
|
|
MAC Table
|
Support MAC address table configuration
|
|
QoS
|
Support QoS base on CoS/DPL/PCP/DEI
Each port support 8 output queue
Support port shaping
Support port tag remarking
Support QoS base on DSCP
|
|
System Maintenance
|
Support the configuration file upload/download
Support the updated packet upload
System log
|
|
Network Management
|
WEB(http protocol), serial, SNMP
|
