16 Kanal H.265+ AI XVR (2x10TB SATA)Maks. 4K HDCVI kamera desteklerKayıt Performansı: Tüm kanallarda 4K@7fps/4MP@15fps/4M-N&1080P@25fpsIP Kamera Girişi: 16+16, 8MP'ye kadar, 128Mbps Bant GenişliğiÇift Yönlü Konuşma, ve Dahili Mikrofonlu HDCVI Kameralar ile 16 Kanalda SesYüz Tanıma(2 Kanal), Çevre Koruması(Sınır/Alan İhlali-2 Kanal), Akıllı Hareket Algılama(Tüm Kanallarda)(Tüm Analizler Kayıt Cihazı Üzerinden Yapılmaktadır)1 HDMI, 1 VGA, 2 USB, 1 RJ45 port(10/100/1000Mbps), Alarm Giriş/Çıkış: 16/3, P2P(Buluttan İzleme)
XVR5216A-4KL-I2
16 Channel Penta-brid 4K-N/5MP 1U 2HDDs WizSense Digital Video Recorder
> H.265+/H.265 dual-stream video compression
> Supports HDCVI/AHD/TVI/CVBS/IP video inputs
> Max 32 channels IP camera inputs, each channel up to 8MP; Max 128 Mbps incoming bandwidth
> Up to 2 channels video stream ( analog channel ) Perimeter Protection
> Up to 16 channels video stream ( analog channel ) SMD Plus
> Up to 2 channels video stream (analog channel ) human face recognition
> IoT & POS functionalities
System
Main Processor
Embedded Processor
Operating System
Embedded LINUX
Perimeter Protection
Performance
2 channels, 10 IVS for each channel
Object classification
Human/Vehicle secondary recognition for tripwire and intrusion
AI Search
Search by target classification (Human, Vehicle)
Face Recognition
Performance
Max 12 face pictures/sec processing
2 channels video stream face recognition, only support analog camera
Stranger Mode
Detect strangers' faces (not in device's face database). Similarity threshold can be set manually.
AI Search
Up to 8 target face images search at same time, similarity threshold can be set for each target face image.
Database Management
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture.
Database Application
Each database can be applied to video channels independently .
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Alarm input
16
Relay Output
3
Playback and Backup
Playback
1/4/9/16
Search Mode
Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode
USB Device/Network
Storage
Internal HDD
2 SATA Ports, up to 10TB capacity for each disk
eSATA
N/A
Auxiliary Interface
USB
2 USB Ports (1 USB 2.0 , 1 USB 3.0)
RS485
1 Port, for PTZ Control
RS232
N/A
Electrical
Power Supply
DC 12V/5A
Power Consumption
(Without HDD)
<15W
Construction
Dimensions
1U, 375 mm × 288 mm × 53 mm
(14.76'' × 11.30'' × 2.09'')
Net Weight
(without HDD)
1.9 kg (4.2 lb)
Gross Weight
3.2 kg (7.0 lb)
Installation
Desktop installation
Environmental
Operating Conditions
-10°C to +55°C (+14°F to +131°F), 0–90% RH
Storage Conditions
-20°C to +70°C (-4°F to +158°F) , 0–90% RH
Third-party Support
Third-party Support
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Certifications
Certifications
FCC: Part 15 Subpart B
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
