| Specification Camera |
|
|
| Image Sensor |
: |
1/3" Progressive Scan CMOS |
| Min. Illumination |
: |
Color: 0.001 Lux @(F1.0, AGC ON), 0 Lux with white light |
| Shutter Speed |
: |
1/3 s to 1/100, 000 s |
| Slow Shutter |
: |
Yes |
| Wide Dynamic Range |
: |
120 dB |
| Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens |
|
|
| Focal Length & FOV |
: |
2.8 mm, horizontal FOV 96.5°, vertical FOV 50.8°, diagonal FOV 113.9°
4 mm, horizontal FOV 75.8°, vertical FOV 40.8°, diagonal FOV 89.1° |
| Lens Mount |
: |
M12 |
| Focus |
: |
Fixed |
| Aperture |
: |
F1.0 |
| DORI |
|
|
| DORI |
: |
2.8 mm, D: 64.0 m, O: 25.4 m, R: 12.8 m, I: 6.4 m
4 mm, D: 77.4 m, O: 30.7m, R: 15.5m, I: 7.7 m |
| Illuminator |
|
|
| Smart Supplement Light |
: |
Yes |
| White Light Range |
: |
Up to 30 m |
| Video |
|
|
| Max. Resolution |
: |
2560 × 1440 |
| Main Stream |
: |
50 Hz:
20 fps (2560 × 1440),
25 fps (1920 × 1080, 1280 × 720) 60 Hz:
20 fps (2560 × 1440),
30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
: |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
: |
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
: |
32 Kbps to 8 Mbps |
| H.264 Type |
: |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
: |
Main Profile |
| H.264+ |
: |
Main stream supports |
| H.265+ |
: |
Main stream supports |
| Region of Interest (ROI) |
: |
1 fixed region for main stream |
| Audio |
: |
|
| Audio Compression |
: |
UF: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate |
: |
UF: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC) |
| Audio Sampling Rate |
: |
UF: 8 kHz/16 kHz |
| Environment Noise Filtering |
: |
UF: Yes |
| Network |
|
|
| Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View |
: |
Up to 6 channels |
| API |
: |
Open Network Video Interface, ISAPI |
| User/Host |
: |
Up to 32 users. 3 levels: administrator, operator and user |
| Client |
: |
iVMS-4200, Hik-Connect |
| Web Browser |
: |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| Image |
|
|
| Image Settings |
: |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch |
: |
Day, Night, Auto, Schedule |
| Image Enhancement |
: |
BLC, 3D DNR |
| Interface |
|
|
| Ethernet Interface |
: |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
: |
UF: Built-in memory card slot, support microSD card, up to 256 GB |
| Built-in Microphone |
: |
UF: Yes |
| Hardware Reset |
: |
UF: Yes |
| Event |
|
|
| Basic Event |
: |
Motion detection, video tampering alarm, exception |
| General |
|
|
| Linkage Method |
: |
Upload to FTP/memory card (-UF), notify surveillance center, send email,
trigger recording (-UF), trigger capture |
| Camera Material |
: |
Metal & Plastic |
| Camera Dimension |
: |
Ø109.9 mm × 103.6 mm (Ø4.33" × 4.08") |
| Package Dimension |
: |
150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") |
| Camera Weight |
: |
Approx. 380 g (0.84 lb.) |
| With Package Weight |
: |
Approx. 600 g (1.32 lb.) |
| Storage Conditions |
: |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
| Startup and Operating Conditions |
: |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing) |
| Web Client Language |
: |
English, Ukrainian |
| General Function |
: |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Firmware Version |
: |
V5.5.122 |
| Power Consumption and Current |
: |
12 VDC, 0.4 A, max. 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
| Power Supply |
: |
12 VDC ± 25%
PoE: 802.3af, Class 3 |
| Power Interface |
: |
Ø5.5 mm coaxial power plug |
| Approval |
|
|
| EMC |
: |
FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
: |
UL (UL 60950-1);
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment |
: |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
: |
IP67 (IEC 60529-2013) |
